Fulham FireHorse FHUPS1-UNV-12L-SD Emergency Micro Inverter, 12W Programmable, 100-277V, 120/220/260V Output, 90 Min Backup, 0-10V & TRIAC Dimming, UL924.
4.0 (43 items)
Limited Time SaleUS$73.44 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 221489336 | Release Date | 2026/05/03 | List Price | US$48.96 | Model Number | 221489336 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
The Fulham FireHorse FHUPS1-UNV-12L-SD is a 12W programmable emergency micro inverter designed to convert standard LED luminaires into code-compliant emergency lighting systems. Featuring sine wave output and auto-select 120/220/260VAC output voltage, this inverter provides seamless emergency power to connected fixtures. Operating from a universal 100-277VAC input range, the unit supports up to 12W (30VA) emergency output. When paired with 0-10V dimming, it can support luminaires up to 100W load, or up to 18W when used with TRIAC dimming. The integrated DIP switch allows configuration for dimming applications. The built-in 11.1V 5000mAh lithium-ion battery (55.5Wh) delivers a minimum of 90 minutes of emergency runtime and recharges fully within 24 hours. The factory-enabled Self-Diagnostic system performs automatic testing and displays system status via a bi-color LED test switch, which can be mounted remotely up to 65.6 feet. Certified to UL924 and CSA standards and designed for dry and damp locations (IP20), this micro inverter is ideal for 2x2 and 2x4 LED troffers, ceiling luminaires, and commercial lighting systems requiring emergency backup power.
- 12W Emergency Micro Inverter: Output Power: 12W Max (30VA). Auto-select output voltage: 120/220/260VAC. Sine wave output. Single channel.
- PRODUCT DIMENSIONS: Length: 12.764 in, Width: 2.657 in, Height: 1.488 in | REMOTE MOUNTING DISTANCE: Up to 150 ft with 18AWG wire | TEST SWITCH WIRE LENGTH: 23 in (584.2 mm)
- Universal Input Voltage: 100-277VAC: Input Voltage: 100-277VAC, 50/60Hz. Input Current: 0.12A Max. Standby power meets CEC requirements.
- 90-Minute Emergency Backup: Battery: 11.1V Lithium-Ion, 5000mAh, 55.5Wh. Minimum discharge time: 90 minutes. Recharge time: 24 hours.
- 0-10V and TRIAC Dimming Compatible: Supports up to 100W load with 0-10V dimming and up to 18W load with TRIAC dimming. DIP switch selectable.
- Self-Diagnostic (SD) Function: Factory-enabled automatic self-testing with bi-color LED test switch. Remote mounting distance: 65.6 ft (20m) max.
| UPC | 847098051251 |
|---|---|
| Brand | Fulham |
| Color | White |
| Model Name | FireHorse |
| Manufacturer | Fulham |
| Model Number | FHUPS1-UNV-12L-SD |
| BuiltIn Media | Emergency Micro Inverter, Test Switch Wire |
